BODY SHAPE |
ML |
BODY BACK
| Mahogany & Top Material: Ash Veneer On Flat Top with Gloss Finish |
HEADSTOCK |
Straight Heritage |
TUNERS |
Chapman Classic Closed (18:1 Gearing) |
STRING NUT |
Graph Tech Black Tusq XL |
STRING RETAINER |
Vintage String Retainers |
NECK |
Maple with Satin Finish |
NECK JOINT |
Recessed Bolt-On |
NECK SIZE |
WIDTH: NUT 42mm, 22F 57mm
THICKNESS including fret height: 1F 22.5mm 12F 24.5mm |
NECK PROFILE |
"C" |
TRUSS ROD |
Dual Action |
FRETBOARD |
Macassar Ebony Fretboard with Rolled Edges |
FRETBOARD RADIUS |
240mm |
NECK FINISH |
Satin |
FRETS |
22 Jumbo, Nickel |
FRET MARKERS |
Pearl Dots |
12TH FRET INLAY |
Pearl Infinity |
SCALE LENGTH |
25.5" (648mm) |
PICKUP SWITCH |
5 Way Blade Switch |
CONTROLS |
Master Volume (500k), Master Tone (500k) |
BRIDGE |
Chapman Hardtail |
Pickup |
Bridge Pickup: Chapman Humbucker - Magnet: Alnico 5, Output: 15.75k ohms
Middle Pickup: Chapman Single Coil - Magnet: Alnico 5, Output: 6.4k ohms
Neck Pickup: Chapman Single Coil - Magnet: Alnico 5, Output: 6.4k ohms |
