BODY SHAPE |
ML3 |
BODY TOP
| Ash Veneer On Flat Top with Satin Finish |
HEADSTOCK |
Angled Heritage Headstock |
TUNERS |
Chapman Classic Closed (18:1 Gearing) |
STRING NUT |
42mm Graph Tech Black TUSQ XL Nut |
STRING RETAINER |
|
NECK |
Maple with Satin Finish |
NECK JOINT |
Recessed Bolt-on Neck |
NECK SIZE |
WIDTH: NUT 42mm, 22F 57mm
THICKNESS including fret height: 1F 22.5mm 12F 24.5mm |
NECK PROFILE |
C Shape |
TRUSS ROD |
Dual Action |
FRETBOARD |
Macassar Ebony Fretboard with Rolled Edges |
FRETBOARD RADIUS |
350mm (~13.5″) |
TUNERS |
Grover |
FRETS |
24 Jumbo Nickel Frets |
FRET MARKERS |
Pearl Side Dots and Pearl Front Dot Inlays |
12TH FRET INLAY |
Pearl Infinity |
SCALE LENGTH |
648mm (~25.5″) |
PICKUP SWITCH |
3 Way Blade Switch with Coil Split on Push-Pull Tone Knob |
CONTROLS |
Master Volume (500k), Master Tone with Push-Pull (500k) |
BRIDGE |
Chapman String-Through Hardtail |
STRAP BUTTONS |
Chapman Classic Strap Buttons |
